Farsight's Advanced Exchange Access, part 2 of 3

Sratool

This is the second article in a three-part blog series intended to introduce and acquaint the user with Farsight’s AXA suite of tools and library code. Thispiece introduces

sratool

and will show useful examples of how to invoke the tool using common use cases. This article is not an exhaustive treatise on

sratool

. For that, the reader is directed to the man page and the source code.

Farsight Advanced Exchange Access

First, a recap. When we last convened, you learned about Farsight Security’sfabled Security Internet Exchange (SIE) and the arcane magic used to remotelyconsume it, the Advanced Exchange Access (AXA). Interest piqued, you mused “how can I get me some of that?”. Dear reader,

sratool

is how you get you some of that. Let’s learn more.

The Swiss Army knife

sratool

is the AXA Swiss Army knife. It is a versatile tool used to test, debug, inspect, or stream AXA connections. In its most common invocation,

sratool

connects to an SRA server, issues a few AXA protocol messages, and displays the responses.

So let’s get to it!

Tutorial 1: Watch Newly Observed Domains

As a stalwart protector of your organization’s network you’ve already contacted Farsight sales and signed up to receive Farsight’s Newly Observed Domains (NOD) datafeed to watch newly active domains and ensure your users don’t visit any newly minted — often malicious — domains.This tutorial will show you, venturesome new Farsight datafeed subscriber, how to examine the Newly Observed Domains (NOD) feed in real time. Commands and their output are listed with discussion below.

1 $ sratool
2 > connect ssh:

• , and use the

• Lines 1-3: Invoke

sratool

connect

• command to establish aconnection to the SRA server. The connection is managed via SSH, meaningall of the benefits conferred by the SSH protocol are available to

sratool

• . Upon success, the client emits the hello string from the

AXA_P_OP_HELLO

• message which was sent by the server and contains the server’s software version, name, and AXA protocol verison.
• Lines 4-5: Inform the server we want to watch SIE channel 211 traffic(this is the NOD channel). The server responds with the current watch status. The watch is the most fundamental sratool command. This is how sratool “signs up” to receive data from the SRA server. As its name implies, watch sets up a watch which is a low-level primitive that tellsthe SRA server that the client is interested in nmsg messages or IP packetsthat meet one of the following criteria:
  • is to, from, or contains the specified address
  • contains the specified domain name
  • arrived on the specified SIE channel
  • are SIE messages that could not be decoded
  A watch is given a tag that is an integer label used to refer to the watch.An SRA server connection or session can have zero or more watches at a time and the user can add or delete watches as needed. Note that sratool allowsonly a single SRA connection at a time.
• Line 6: Using the

count

• command, we inform

sratool

• we only want to see 5 packets. After this number is met,

sratool

• will stop emitting packets to the screen (though traffic may still be flowing from server to client).
• Lines 7-8: With the

channel

• command, enable channel 211 (NOD). The current channel status is printed. Another fundamental command to

sratool

• is

channel

• . Issued alone on the command-line, it will emit the entire listof available SIE channels for which the user is provisioned.
• Lines 9-19:

sratool

• emits 5 NOD packets as it receives then from the server. Once the packet count limit is reached, emission stops.
• Lines 20-21: Issuing the

count

• command with no arguments prints the current count status. In this case, we find 1990 NOD packets have beenstreamed to the client, but since we exceeded our limit, they were notemitted to the screen.

Tutorial 2: counts and limits

Continuing in the session above, let’s tweak a few knobs and press a few buttons.

22 > list watches
23 1 ch=ch211
24 > 1 delete
25 1 OK STOP watch deleted
26 > rate
27 RATE LIMITS
28 unlimited per second; current value=307
29 10 seconds between reports
30 > rate 1
31 RATE LIMITS
32 1 per second; current value=2
33 10 seconds between reports


• Lines 22-23: The list watches command prints all of the active watches. We’ve still got one going, we’re just not emitting any packets to the screen.
• Lines 24-25: We delete the watch by referencing its tag with the deletecommand.
• Lines 26-29: Another handy command, rate allows us to query the rate limiter and control it. Currently, there is no rate limiting in play —packets will be emitted as quickly as they appear. For lower bandwidthchannels, like NOD, this is might not be a problem. For the DNSDB channels,which are much higher bandwidth, we’ll want to limit the rate at which thosepackets are sent by the server to

sratool

• .
• Lines 30-33: Using the rate command, we set a rate limit of 1 packet persecond. This will come in handy in the last part of the tutorial where we’llexamine DNSDB.

Tutorial 3: watch for a specific domain in Farsight’s passive DNS feed

As a bonus, let’s peek at SIE channel 202 traffic, Farsight’s raw passive DNSfeed.

34 > 2 watch dns=*.github.com
35 2 OK WATCH started
36 > channel 202 on
37 * OK CHANNEL ON/OFF channel ch202 on
38 2 ch202 base dnsqr response UDP_QUERY_RESPONSE
39 204.13.250.16.53 > 68.105.29.142.17296 IP TTL=58 UDP 86 bytes
40 DNS: raw.github.com IN A qr aa NOERROR 1 ans, 0 auth, 0 add RRs
41 2 ch202 base dnsqr response UDP_QUERY_RESPONSE
42 208.78.71.16.53 > 208.106.17.39.64372 IP TTL=56 UDP 153 bytes
43 DNS: api.github.com IN A qr aa cd NOERROR 1 ans, 4 auth, 0 add RRs
44 2 ch202 base dnsqr response UDP_QUERY_RESPONSE
45 204.13.250.16.53 > 68.105.28.174.52707 IP TTL=58 UDP 89 bytes
46 DNS: malsup.github.com IN A qr aa NOERROR 1 ans, 0 auth, 0 add RRs
47 * MISSED
48 lost 0 input packets, dropped 0 for congestion,
49 121 for per sec limit
50 since 2014/12/08 17:29:38
51 2 ch202 base dnsqr response UDP_QUERY_RESPONSE
52 204.13.250.16.53 > 68.105.28.174.47116 IP TTL=58 UDP 149 bytes
53 DNS: github.com IN A qr aa NOERROR 1 ans, 4 auth, 0 add RRs


• Lines 34-35: We set another watch, this time we want to watch for thewild card domain “*.github.com”. Anything matching this domain will be emitted, such as www.github.com and

github.com

• itself.
• Lines 36-37: We turn on channel 202, Farsight’s raw passive DNS channel.
• Lines 38-53: All domains matching the watch are emitted.

This should be enough to get you started! Next week, we’ll cover

sratunnel

!

Denouement

We learned how to invoke

sratool

, issue some fundamental commands to turn on,off, and control the flow of SIE data.

Our next and final installment in this introductory tutorial will be a discussion of

sratunnel

.

Mike Schiffman is a Senior Distributed Systems Engineer for Farsight Security,Inc.
